Description

General
Brand
  • Gigabyte
Model
  • Z590-AORUS-MASTER
Microless SKU
  • 76856
Date first available
  • 22 April, 2021
Maximum Capacity
  • 128GB DDR4,
Expansion Slots
  • 1 x PCIe 4.0 x16
    1 x PCIe 4.0 x16 (x8 mode)
    1 x PCIe 3.0 x16 (x4 mode)
Chipset
  • Intel Z590
Form Factor
  • ATX
Other
  • BIOS
    ROM 256 Mb
    Front Panel I/O
    I/O Connection Headers USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2
    Audio
    Audio Codec Realtek ALC1220-VB (7.1-Channel)
    Wireless
    Bluetooth 5.2
    Wi-Fi Wi-Fi 6 (802.11ax) (MU-MIMO)
    Software
    Supported Operating Systems Windows 10 (64-Bit)
    Physical
    Form Factor ATX
    Dimensions 9.6 x 12.0\” / 24.4 x 30.5 cm
    Packaging Info
    Package Weight 5.855 lb
    Box Dimensions (LxWxH) 13.7 x 11.7 x 3.3\”
General
  • CPU
    Chipset Intel Z590
    CPU Socket LGA 1200
    Back Panel I/O
    USB 1 x USB 3.2 Gen 2×2 Type-C
    5 x USB 3.1 / USB 3.2 Gen 2 Type-A
    4 x USB 3.1 / USB 3.2 Gen 1 Type-A
    Thunderbolt None
    Display 1 x DisplayPort
    Audio 5 x 3.5 mm
    1 x S/PDIF
    Ethernet / Controller 1 x Aquantia 10GbE
    Wi-Fi Antenna 2 x Connector
    Buttons BIOS Flashback, Clear CMOS
    Memory
    Memory Slots 4 x 288-Pin
    Memory Support DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333, 5400 MHz
    Maximum Capacity 128 GB
    Channel Architecture Dual Channel
    ECC Support Non-ECC, ECC Unbuffered
    Storage Expansion
    SATA 6 x SATA III
    M.2 1 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, PCIe 4.0 x2, PCIe 3.0 x4, PCIe 3.0 x2)
    2 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, PCIe 3.0 x2)
    U.2 None
    Optane Memory Support Yes
    RAID Support RAID 0, 1, 5, 10
    Internal I/O
    Expansion Slots 1 x PCIe 4.0 x16
    1 x PCIe 4.0 x16 (x8 mode)
    1 x PCIe 3.0 x16 (x4 mode)
    USB 1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)
    2 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)
    2 x USB 2.0 Header (Supports 4 USB Type-A Port)
    Multi-GPU Support 2-Way, Quad-GPU AMD CrossFireX
    Air Cooling 1 x 4-Pin CPU
    8 x 4-Pin System
    2 x Thermal Sensor
    1 x Noise Sensor
    Liquid Cooling 1 x 4-Pin Pump
    Power Connectors 1 x 24-Pin Mainboard
    1 x 8-Pin ATX
    Security TPM Module
    LED Header 4 x RGB
    Audio 1 x Speaker
    Diagnostics BIOS Selection, Clear CMOS, Power, Reset
    Add-On 2 x Thunderbolt Card Header
